- Comprehensive Docking Solution: 15 ports including high-resolution HDMI and DisplayPort outputs.
- Enhanced Data Transfer Speed: Offers USB-A 3.2 Gen2 for rapid file transfers.
- Prepare for the future with 8K video output capability. It supports a triple 4K Display.**
- Single-Cable Connection: Simplifies the workspace with one cable to connect multiple devices.
Comprehensive Docking Solution: 15 ports including high-resolution HDMI and DisplayPort outputs.
Enhanced Data Transfer Speed: Offers USB-A 3.2 Gen2 for rapid file transfers.
Prepare for the future with 8K video output capability. It supports a triple 4K Display.**
Single-Cable Connection: Simplifies the workspace with one cable to connect multiple devices.
**HDMI port requires a direct HDMI to HDMI connection.
2 x HDMI, up to 8K@30Hz; 1 x DP, up to 8K@30Hz; 1 x RJ45, up to 1Gb/s; 1 x USB-A 3.1, up to 10Gb/s; 2 x USB-A 3.0, up to 5Gb/s; 1 x USB-A 2.0, up to 480Mb/s; 2 x USB-C 3.1, up to 10Gb/s; 1 x SD 4.0; 1 x Micro SD 3.0; 1 x Audio jack; 1 x USB-C Host ; 1 x USB-C PD, up to 100W
| Ports & interfaces | |
|---|---|
| Connectivity technology | Wired |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| USB Power Delivery | Yes |
| USB Power Delivery up to | 100 W |
| HDMI ports quantity | 2 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4 |
| Combo headphone/mic port | Yes |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 1000 Mbit/s |
| Performance | |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), SD |
| Data transfer rate | 10 Gbit/s |
| HD type | 8K Ultra HD |
| Maximum refresh rate | 120 Hz |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Product colour | Black, Grey |
| LED indicators | Status |
| Plug and Play | Yes |
| Housing material | Acrylonitrile butadiene styrene (ABS), Aluminium |
| Country of origin | China |
| Power | |
| Power source type | USB |
| Power connector | USB Type-C |
| Input current | 0.9 A |
| Software | |
| Windows operating systems supported | Windows 10, Windows 11 |
| Mac operating systems supported | Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.7.5 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 85 °C |
| Operating relative humidity (H-H) | 20 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| Sustainability | |
| Sustainability compliance | Yes |
| Sustainability certificates | REACH, RoHS |
| Weight & dimensions | |
| Width | 68.5 mm |
| Depth | 168 mm |
| Height | 33 mm |
| Weight | 308 g |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Package width | 115 mm |
| Package depth | 220 mm |
| Package height | 36 mm |
| Package weight | 406 g |
| Technical details | |
| Compliance certificates | REACH, RoHS |
